Classifier CF120 Series
10 mTPH
15 (20)
200
Classifier CF200 Series
20 mTPH
22 (30)
400
Classifier CF200 Series
45 mTPH
22 (30)
900
Model | CF120 | CF200 | CF300 |
---|---|---|---|
Maximum feed rate (m3/hr) | 200 | 400 | 900 |
Sludge flow rate, mtph | 10 | 20 | 45 |
Sludge pump power, kw(hp) | 15 (20) | 22 (30) | 22 (30) |
Rake power requirement, kw(hp) | 3.3 (4.5) | 3.3 (4.5) | 3.7 (5) |
Tank diameter, m | 6 | 8 | 12 |
Flocculant station power, kw (hp) | 3 (4) | 3 (4) | 3 (4) |
Total power kw (hp) | 22.05 (30) | 29.05 (39) | 30 (40) |
