Increased speed, installed power and mechanical improvements.
New set of shells and concaves brings less downtime.
Detailed reports and intelligent measurement of crushing operations.
Hydraulic separation and individual lifting of shells.
| Model | HF150 | HF220 | HF270 | |
|---|---|---|---|---|
| Drive power, kw (hp) | 75 - 110 (100 - 150) | 132 - 160 (180 - 220) | 132 - 220 (175 - 300) | |
| Total weight, kg (lbs) | 10520 (23143) | 13500 (29765) | 15800 (34833) | |
| Stroke options, mm (in) | 25,30 (1, 13/16) | 18,22,28,36 (11/16, 7/8, 17/64, 113/32) | 18,25,28,32,36,40 (11/16, 1, 17/64, 11/4, 113/32, 19/16) | |
| Feed opening | ||||
| Fine, mm (in) | - | - | 90 (335/64) | |
| Medium fine, mm (in) | 95 (33/4) | 90 (327/50) | - | |
| Coarse, mm (in) | >160 (65/16) | >172 (619/25) | 213 (782/5) | |
|
Closed Side Setting mm (In) |
Capacity (Mtph) | |||
| HF150 | HF220 | HF270 | ||
| 8 ( 5/16) | - | - | 70 - 90 | |
| 10 (3/8) | 58 - 95 | 70 - 90 | 80 - 130 | |
| 15 (19/32) | 65 - 123 | 77 - 99 | 105 - 175 | |
| 20 (25/32) | 84 - 135 | 100 - 110 | 120 - 230 | |
| 25 (1) | 105 - 147* | 126 - 165 | 150 - 265 | |
| 30 (1 3/16) | 132 - 160* | 144 - 205 | 165 - 280 | |
| 35 (1 3/8) | - | 162 - 250 | - | |
| 40 (1 9/16) | - | 175 - 260 | - | |
| 200 (8) | 400 - 520 | 390 - 550 | 430 - 645 | |
| Model | EC2500 | EC3000 | EC3500 | EC4000 | |
|---|---|---|---|---|---|
| Maximum feed opening, mm (in) | 190 (71/2) | 200 (77/8) | 241 (91/2) | 255 (10) | |
| Total weight, kg (lbs) | 17000 (37480) | 21500 (47400) | 24000 (52911) | 26500 (58423) | |
| Drive power, kw (hp) | 160 (220) | 225 (300) | 250 (330) | 315 (425) | |
|
Closed Side Setting mm (In) |
Capacity (Mtph) | ||||
| EC2500 | EC3000 | EC3500 | EC4000 | ||
| 8 (5/16) | - | 90 - 130 | - | 135 - 175 | |
| 10 (3/8) | 99 - 143 | 105 - 150 | 127 - 154 | 155 - 210 | |
| 13 (1/2) | 132 - 176 | 130 - 185 | 165 - 204 | 195 - 265 | |
| 16 (5/8) | 149 - 204 | 155 - 230 | 198 - 242 | 235 - 315 | |
| 19 (3/4) | 165 - 215 | 180 - 250 | 220 - 264 | 260 - 345 | |
| 22 (7/8) | 176 - 231 | 190 - 260 | 242 - 286 | 285 - 375 | |
| 25 (1) | 187 - 253 | 210 - 290 | 253 - 308 | 300 - 400 | |
| 32 (1 1/4) | 204 - 264 | 220 - 310 | 275 - 352 | 310 - 440 | |
| 38 (1 1/2) | 220 - 286 | 240 - 350 | 330 - 418 | 360 - 500 | |
| 45 (1 3/4) | - | 280 - 400 | 385 - 484 | 400 - 555 | |
