Track Mounted Jaw Crushers
127 mtph - 520 mtph
1100 x 4200 (43.3 x 165.3)
600
| TRACK MOUNTED JAW | HAILTRACK-HT Series |
|---|---|
| Model | HT130 |
| Crusher | |
| Model | JC130 |
| Opening Size, mm (in) | 1067 x 813 (42 x 32) |
| CSS Range, mm | 70 - 200 |
| *Capacity, mtph | 127 - 520 |
| System | |
| Hopper Capacity, m3 | 6/10* |
| Grizzly Feeder | GFEM4211 |
| Feeder Size, mm (in) | 1100 x 4200 (43.3 x 165.3) |
| Main Conveyor | |
| Belt Width, mm (in) | 1000 (39.4) |
| Discharge Height, mm (in) | 3800 (149.6) |
| Stock Pile Capacity, m3 @ 40° | 82 |
| Bypass Conveyor | |
| Belt Width, mm (in) | 500 (19.7) |
| Discharge Height, mm (in) | 2000 (78.8) |
| Stock Pile Capacity, m3 @ 40° | 12 |
| Under Carriage | |
| Shoe Width, mm (in) | 500 (19.7) |
| Gradability | 30° |
| Hydraulic Tank Capacity, litre | 300 |
| Power Unit | |
| Power, kW | 190 |
| Generator power, kVA | 320 |
| Engine | Volvo/CAT with Stamford Alternator |
| Diesel Tank Capacity, litre | 600 |
| Dimensions | |
| Transportation (L x W x H), mm (in) | 14614 x 3350 x 3633 (575.4 x 131.9 x 143.1) |
| Working (L x W x H), mm (in) | 16399 x 3350 x 4199 (645.7 x 131.9 x 165.4) |
| Weight, kg (lbs) | 53000 (116845) |
| *Optional | |
