Increased speed, installed power and mechanical improvements.
New set of shells and concaves brings less downtime.
Detailed reports and intelligent measurement of crushing operations.
Hydraulic separation and individual lifting of shells.
Bucket Wheel Classifier BCD1209 Series
45 - 60 mTPH
3.29
5.5kW (7.5hp)
Bucket Wheel Classifier BCD1412 Series
60 - 80 mTPH
3.29
7.5kW (10hp)
Bucket Wheel Classifier BCD1815 Series
90 - 120 mTPH
3.32
15kW (20hp)
Bucket Wheel Classifier DUO80 Series
40 - 80 mTPH
3.29
5.5kW (7.5hp)
Bucket Wheel Classifier DUO120 Series
70 - 90 mTPH
3.29
7.5kW (10hp)
Bucket Wheel Classifier DUO160 Series
100 - 130 mTPH
3.29
7.5kW (10hp)
| Model | BCD1209 | BCD1412 | BCD1815 |
|---|---|---|---|
| Drive power, kw (hp) | 5.5 (7.5) | 7.5 (10) | 15 (20) |
| Rotation speed, rpm | 3.29 | 3.29 | 3.32 |
| Unbalanced motor power, kw | 2 x 1.5 | 2 x 1.5 | 2 x 3.8 |
| Number of products | 1 | 1 | 1 |
| Capacity, mtph | 45 - 60 | 60 - 80 | 90 - 120 |
| Maximum feed size, mm | < 8 | < 8 | < 8 |
| Approximate weight, kg (lbs) | 7622 (16804) | 8522 (18788) | 12032 (26526) |
| Dewatering screen size (L x W), mm (in) | 2100 x 900 (83 x 35) | 2100 x 1200 (83 x 47) | 2450 x 1500 (96 x 59) |
| Model | DUO80 | DUO120 | DUO160 |
|---|---|---|---|
| Drive power, kw (hp) | 5.5 (7.5) | 7.5 (10) | 7.5 (10) |
| Rotation speed, rpm | 3.29 | 3.29 | 3.29 |
| Unbalanced motor power, kw | 2 x 1.5 | 2 x 2.2 | 2 x 1.5 (DWS) 2 x 3.8 (RS) |
| Number of products | 2 | 2 | 2 |
| Capacity, mtph | 40 - 80 | 70 - 90 | 100 - 130 |
| Maximum feed size, mm | < 8 | < 8 | < 8 |
| Approximate weight, kg (lbs) | 5440 (11993) | 8630 (19026) | 13164 (29022) |
| Dewatering screen size (L x W), mm (in) | 2117 x 1270 (83 x 50) | 2480 x 1446 (98 x 57) | 1840 x 1146(DWS) (73 x 33) 2800 x 1300(RS) (110 x 51) |
